Lab 3: Debugging with GDB

In this lab, you will get hands-on experience using GDB to debug C programs. GDB will become an essential tool for your Project work as this course develops, so lock in!

Lab 3 learning objectives

• Recognize the need for debugging using a debugger
• Compile a C program for debugging
• Catch possible bugs using a compiler
• Run a program in GDB while stopping at breakpoints
• Use various GDB commands to observe and control program execution
• Use GDB to troubleshoot a crashing program

Whiteboard activity #1

Icebreaker

The CSE 29 genie, which runs on ieng6, would like to grant you 3 wishes. You may wish for anything you want, except you may not wish recursively (i.e., wish for more wishes). What do you wish for?

Warm-up

Color ls

1. if you did not opt to make your ls colorful in week1, now is the time.
2. Run echo alias ls=\"ls --color\" >> ~/.bash_profile
   • if you have file permission issues, you can use chmod u+rwx ~/.bash_profile
3. you can use source ~/.bash_profile to apply these changes right now.

Part 1: -W(arn)all

Our compiler gcc is designed to catch possible errors at compile time and warn you. While it gives you some of these warnings by default, we can force it to display all possible errors it detects by telling it to W(arn) all using -Wall flag. We can add this flag as follows:
gcc myprogram.c -o myprogram -Wall

Part 2: What and why debugging?

Debugging is the practice of finding and fixing errors in programs. There are no real bugs in your program, although this has actually happened at least once before.

Like programming, debugging is also an incremental process. Programmers often need to isolate and debug one error at a time, rather than all errors at once.

We could insert some print statements into our code to try and figure out what’s going on—for small programs, print statements are often enough! However, there are several situations where we would want to use a debugger instead:

1. If your program reports a segmentation fault, it can be difficult to pin down exactly where the segfault took place using print statements. A debugger can pause your program when it crashes and enable you to inspect its final state.
2. If you are searching for a bug in a loop with many iterations, searching through print statement output from that loop can be quite cumbersome.
3. You might work on a program for which you can’t see the output of print statements (like your web browser or vim itself). In this case, the debugger is a convenient tool for inspecting program state.

GDB (GNU Project Debugger) is a command line program that offers a convenient way for us to pause execution at any point in the code, manually inspect the values of any variable in the scope, and walk through the program step-by-step.

Debugging Activity

The gdb directory contains several programs which we will debug with GDB: index_of_E and charshift.c. We’ll start with the index_of_E program to introduce basic GDB commands, then look at charshift.c to talk about segmentation faults and how to debug them with GDB.

The correct behavior of index_of_E is to find the index of the first occurrence of the character E in a string str.

Compiling for GDB

In order to use GDB, we have to compile our program with the -g flag. This tells the compiler to add some extra information to your executable file, which GDB will use. index_of_E was compiled using the following command.

$ gcc -o index_of_E -g index_of_E.c

Running in GDB

To run the program in GDB, use the gdb and pass the program as an argument:

$ gdb ./index_of_E

This will spit out several lines of text, with some software and legal information that we don’t need to worry about. In the last line, you should notice that the terminal command prompt $ (as well as the other stuff before $) has been replaced by the GDB command prompt (gdb). This means that the GDB program is active and ready to receive commands.

Use the run command to run the program in GDB. Since this program takes in a command line argument, you can provide it like so:

(gdb) run CSE29_is_fantastic!

This is just like running the command ./index_of_E CSE29_is_fantastic!. For now, it runs through the program without stopping. GDB might say something here about “Missing separate debuginfos”, but don’t worry about this. GDB is just asking to install some extra packages to get more information for debugging, but these aren’t necessary for our purposes right now.

To quit out of GDB, you can use the quit command.

(gdb) quit

Breakpoints

To pause execution at some point in the program, we have to set a breakpoint. Restart gdb ./index_of_E. Use the break command and give it a location in the source code that you want to pause execution at. At the moment, we’re not too sure exactly which part of the code is wrong, so we’ll pause at the beginning (the main function) and go step-by-step from there. You can use either

(gdb) break main

to automatically set a breakpoint wherever the main function is. which happens to be line 12 in index_of_E.c, or if you had the source code and knew the line number:

(gdb) break index_of_E.c:12

to set a breakpoint at line 12 in the file index_of_E.c, You can set breakpoints at any line in a source file, but usually we find it helpful to set them at the start of functions, to investigate the behavior of a function from its beginning.

You can use the info breakpoints command to list out which breakpoints have been set, as well as some information about where they are and what their associated number is. You can delete breakpoints with the command delete <number> where <number> is the number associated with the breakpoint.

After setting a breakpoint, you can run the program again (copy the run command from earlier) and see that it pauses execution right where the breakpoint is.

Part 3: TUI, Commands, Segfault, and BackTrace

TUI in GDB

Notice that GDB printed out a single line of code from the source file. This is the line of code that is about to be executed next. Here, you can use the list command to print out some of the surrounding code. This can be helpful to contextualize where the code is running.

The layout src command may also be helpful to enable a TUI (Text User Interface) for GDB that automatically renders a portion of the source code in the top half of the screen. The highlighted line in the TUI shows which line of code is to be executed next. To disable the TUI, use tui disable. Alternatively, press Ctrl + X, followed by A.

(gdb) layout src

The TUI won’t render any source code unless there is a program that is active, i.e. in the middle of execution.

Sometimes the TUI can get messed up if the program prints something out (which index_of_E does). When this happens, try using the refresh command to refresh the TUI and hope that it will restore its correct format. If something seems really messed up, try disabling and re-enabling the TUI.

On the left hand side of the TUI, you can see that the breakpoint is marked with B+>.

Basic GDB commands

After setting a breakpoint and running, execution is paused right after we enter the main function, before any other code is executed. You can verify this by using the print command to print out the contents of the variable result:

(gdb) print result

and see that it contains an uninitialized value. We see this because the line that initializes the variable has not been executed yet.

To run the next line of code, we use the next command:

(gdb) next

The highlighted line has moved on, indicating that the previous line has been executed. You can check the values of argc and argv using the print command, which accepts any valid expression in C:

(gdb) print argc
(gdb) print argv
(gdb) print argv[0]
(gdb) print argc < 2

Let the program finish by using the continue command. Does its output match what you expect?

We now know that this input exposes a bug inside index_of_E, so we want to look into this function with GDB. Let’s restart the execution and make line-by-line steps. Run the break main command to have the program stop when the main function begins, and then use the run command to start the program again.

Use next to execute the program up until, but not actually executing, the call to index_of(). You’ll know that index_of() is next to be executed, but not executed yet, when the line of code is highlighted. This time, instead of using next to run the entire index_of() function at once, use the step command to step into the function and begin executing line-by-line from inside:

(gdb) step

Then continue using next to run through the loop and figure out why index_of() is buggy. Try printing out the relevant variables as you go through each iteration. Once you figure out why index_of() isn’t working, write what the problem was along with how you would fix it on your whiteboard.

This buggy program demonstrated an example of a logical error. A logical error is one in which the behavior of the program is different than what we expect it to be, without refusing to compile or crashing at runtime. However, before your fix, it was theoretically possible for this program to crash—why do you think it was? Feel free to verify your thoughts with your peers, tutors or TA.

Segfault and Backtrace

Another common type of error is a segmentation fault (or just segfault). Segmentation faults can happen when we try to access someplace in memory illegally (yes, that’s the technical term). In charshift.c, we’ll look at an example of that.

Compile charshift.c for GDB and try running ./charshift. It should immediately crash and give you a Segmentation fault (core dumped) error, telling you that some kind of illegal memory access happened. Most unhelpfully, the error message does not care to tell you why or even where it happened. Somewhat helpfully, GDB can at least answer the “where”. From this lab onward, whenever you see your program segfaulting, you should consider debugging it with GDB.

Start GDB with the charshift program. This time, instead of setting a breakpoint, we can let the program run through and give us a segmentation fault. GDB immediately tells us where the segfault happened and gives us a line number. From the output, we can see that the segfault occurred in shift_chars(), where we attempt to dereference the pointer and see if it is in the range of capital letters. But main() calls shift_chars(), so which one is the one causing the error?

Here, we can use the backtrace command (or the shorter bt) to show a backtrace (also called a stack trace) of the functions that were called leading up to the segfault. The output shows that the segfault happened in shift_chars(), when shift_chars() was called from main() at a certain line. This helps you discern which specific call to a function causes a segfault, when you have multiple calls to the same function. Feel free to run layout src to help you find the line referenced from the backtrace.

Since we know that segfaults are caused by illegal memory access, and we know that line 6 in charshift.c caused a segfault, we can infer that ch probably contains an address that the program can’t access legally. Confirm this by running print ch. Then, run print str to see the address of the beginning of the message. What do you notice between these two addresses, and what does that imply about the loop in shift_chars? This should help you pinpoint and fix the bug. Feel free to work with your peers and ask your tutors/TAs for a hint if you’re stuck!

Debugging practice

Identify yourself to ieng6

With this setup, each time you log in to your ieng6 account, you have to type the password. This can get a bit tedious. Luckily, there is a cool and interesting way to avoid this while still staying secure using SSH keys. You should perform the following on the device your frequently ssh into ieng6 from, not particularly on a lab computer.

1. Verify that you are not logged into ieng6. If your prompt does not contain the string ieng6, then you’re probably not on it.
2. Run ssh-keygen -t rsa -b 4096. This command will generate a pair of SSH keys for you: one public (ends in .pub) and one private. If the program claims that the keys already exist, answer the Overwrite (y/n)? prompt with n to prevent overwriting your existing keys. Otherwise, keep pressing <Enter> until the program shows some text it calls the “randomart image”.
3. Expand the instructions that match your system below:

Try to log onto your remote account again. You shouldn’t be prompted for a password anymore. If you are, ask for help and carefully review the steps above with your group.

Next steps

If you finish with the lab content above you may any do the following:

• Work on Problem Set 2
• Project 1 Resubmission
